Formica pvc u shape edge banding 902

Shanghai Luyao Industrial Co., Ltd. is your first choice for edge banding solutions. Our Formica pvc u shape edge banding 902 is an ideal choice for furniture manufacturers, cabinet makers and interior designers with its excellent bonding performance, wide range of color and texture options, and environmentally friendly materials. Whether you are working on a large commercial project or a small DIY project, our U-shaped edge banding can meet your needs.

Product Description

Application: Suitable for edge banding of various types of MDF and particleboard.
Adhesion: Perfect bonding with hot melt adhesive ensures durability.
Color and Texture: A variety of colors and wood grain designs are available.
Finish: Options include smooth, high gloss, matrix, pearl, ash pore, wood pore and wood grain finishes.
Physical Protection: Provides excellent protection against physical damage.
Use: Widely used for panel edge banding in furniture production.

Product Specifications

Color: Due to different production times, there may be slight color differences between samples and actual products.
Color Fastness: All products are printed with inks with a color fastness rating of 6-8.
Gloss: According to ISO 2813 (measurement angle = 60°):
High gloss solid color: ±93
High gloss wood grain: ±93
Wood grain: ±17
Embossed surface: ±7
Dimensional stability: Shrinkage is less than 1.5% after 1 hour at 80°C according to DIN 53377.
Density: Ranges from 1.35 to 1.4, in accordance with DIN 53479.
Water absorption: Negligible according to ISO 62.

Available dimensions

Width: Customizable according to customer needs (e.g. 22mm, 33mm, 42mm, 44mm).
Standard lengths:
0.4mm thickness PVC roll: 300 meters
0.8mm thickness PVC roll: 150 meters
1mm thickness PVC roll: 150 meters
2mm thickness PVC roll: 100 meters.

Application Notes

Processing Equipment: PVC edge banding can be processed on a variety of edge banding machines (linear processing and BAZ processing centers) using hot melt adhesive technology. Each machine may require specific adjustments in the process or parameters.
